A: Of course, no matter how many MOQs,we can print the logo for free.
| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | yetnorson |
| Model Number: | yxn gps 2 |
| Minimum Order Quantity: | 2 pieces |
| Price: | $2.87/pieces 2-99 pieces |
| Packaging Details: | 1pcs antenna/PE bag. 200pcs/CTN for 5 In 1 mini internal Passive External Marinated Rtk Gnss Lte Gsm Wifi 4g MIMO Car Gps Combo Antenna |
| Supply Ability: | 20000 Piece/Pieces per Day GPS Antenna Receiver Repeater Signal |
| Type: | GPS/GNSS Antenna | Center Frequency (MHz): | 1575.42~1610MHz |
|---|---|---|---|
| Gain(dBi): | 28dBi | V.S.W.R: | 2:01 |
| Connector: | SMA/Fakry/USB | Cable: | RG174/1~5 Meters |
| Impedance: | 50ohm | Weight: | 60 Gram |
| Size: | 35x30x15mm | Supported Positioning Signal Bands: | GPS (1575.42MHZ) BD (1561MHZ) GLONASS (1601MHZ) |
| Radome: | ABS+PC | Port: | Shenzhen |
GPS&GLONASS Antenna | Frequency Range | 1575.42~1610MHz | ||||
Polarization | RHCP | |||||
Impedance | 50Ω | |||||
Dimension | 10*3*8mm | |||||
Gain | 28±2dB | |||||
Noise Figure | ≤1.5dB | |||||
Supply Voltage | 3~5V DC | |||||
Current Consumption | ＜15mA | |||||
V.S.W.R | ＜2.0 | |||||
LTE Antenna MIMO | Frequency Range | 698~960MHz/1710~2690MHz | ||||
V.S.W.R | ＜3.0 | |||||
Polarization | Linear | |||||
Gain | 2-3dBi | |||||
Impedance | 50Ω | |||||
WIFI Antenna MIMO | Frequency Range | 2400~2483.5MHz/4900~5825MHz | ||||
V.S.W.R | ＜2 | |||||
Polarization | Linear | |||||
Gain | 2-3dBi | |||||
Impedance | 50Ω | |||||
