| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | YNX |
| Model Number: | YNX-00125, YNX-4G-002 |
| Minimum Order Quantity: | 100 pieces |
| Price: | $1.20/pieces 100-999 pieces |
| Packaging Details: | PE bag package of Rubber 2600MHz 4G LTE External Antenna For Router |
| Type: | Cellular Antenna | Key Feature1: | Newest 4G Network Reception |
|---|---|---|---|
| Key Feature2: | Compatible With Many Models | Key Feature3: | Powerful Enhanced Signal |
| VSWR: | 1.5 | Color: | Black |
| Frequency: | 600-2700mhz | Connector: | Customized |
| Gain: | 3db | Length: | 154mm |
High Gain: This 3 dBi stick antenna can increases the range of your wireless device.
Easy Setup: Simply replace current antenna to increase signal strength, no need any drivers plug and play.
Dual-band: With high value Dual-band antennas you can get maximum omnidirectional wireless coverage and reliability
Application: Devices with connector interface, Verizon, AT&T, Sprint, T-Mobile, and all 3G, 4G, LTE,GSM & CDMA cellular services, Wireless Network Router/USB Adapter/PCI PCIe Cards/IP Camera, etc.
Electrical Specifications | ||||||
Frequency Range (MHz) | 600-2700 | |||||
Bandwidth (MHz) | 100~700 | |||||
Input Impendence (Ω) | 50 | |||||
V.S.W.R | ≤1.5 | |||||
Gain (dBi) | 3 | |||||
Polarization Type | Vertical | |||||
Power Capacity (w) | 50 | |||||
Antenna Length (mm) | 154 | |||||
Connect Type | Customized | |||||
Radome Color | Black | |||||
Weight (g) | 25g | |||||
Shenzhen Yetnorson technology Co., LTD. as one of the emerging high-tech enterprise, who is one of the leader engaged in the antenna products, customer service and R&D design. Our main products at GSM/GPS/CDMA/DVB-T/DMB-T/DAB-T/ISDB /PHS / 3 G / 4 G /5.8G, 2.4 GHz (WIFI, wireless local-area network (wlan)-/ 3.5 GHz wimax (5.8 GHz) / wireless spread spectrum communication series.
Our ordinary package is one piece in a PE bag/750pcs in a 66*52*41cm Carton, total gross weight: 35.7kg/ Carton
Delivery time is about 7-15 days after receiving your payment.
1. Why do you order from Yetnorson?
Yetnorson can provide you one-stop shopping with wholesale price.
2. How can we promise you the quality?
Each of our products will be tested 35 times before it shipped,
QC from third department is highly welcome.
3. Why the goods take so long to arrive my place?
That depends on the way of shipment.
If by ship, it is no wonder that will take longer time to arrive you compared with air.
4. How can i select the goods and know the price?
Contact with us by trademanager, email or phone.
Tell us the details of the product you need, then we will reply you within 24 hours.
