| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Yetnorson |
| Model Number: | YNX-4G-YZ002 |
| Minimum Order Quantity: | 100 chains |
| Price: | $8.00/chains 100-9999 chains |
| Packaging Details: | One product with one PE bag packaging, |
| Supply Ability: | 10000 Chain/Chains per Week Dish 4G LTE Antenna with N Female 4G Router with External |
| Frequency: | 698-960 /1710-2700 MHz | Gain(dBi): | 10-12dBi |
|---|---|---|---|
| V.S.W.R: | ≤2.0 | Input Impendence: | 50 OHM |
| Polarization Inten: | Vertical Or Horizontal | Demensions: | 220 * 65 * 65mm |
| Connector Type: | N Female | Input Maximum CW Power: | 50W |
| Temperature Range: | -40C ~ +95C | Port: | Shenzhen |
Frequency Range | 698-960 /1710-2700 MHz |
Gain (dBi) | 10-12dBi |
V.S.W.R | 2.0 |
Input Power | 50W |
Polarization | Vertical/Horizontal |
Radiation Direction | Omni Directional |
Impedance (ohms) | 50Ω |
Connector | N Male Straight |
Connector Plating | Gold |
Housing Material | TPEE & ABS |
Colour | White |
Antenna Type | Outdoor |
Antenna Size | 220mm |
Storage Temperature( °C) | - 40 °C ~ + 80 °C |
Operation Temperature (°C) | - 40 °C ~ + 65 °C |
Humidity(% ) | 5 ~ 95 |
Environment Friendly | RoHS Compilant |
Shenzhen Yetnorson Technology Co.,Ltd is one of the professional antenna maker focus on the development, design, manufacture, sale and Service of radio communications antennas. which has been dedicated to the antenna development likeGSM/CDMA/PHS/3G/4G antenna, 2.4GHz (wi-fi, wlan)/3.5GHz (wimax) /5.8GHz/wi-fi amplifier communication antenna serial(including: all direction, yagi antennas ,3G parabolic antennas, panel antenna, indoor antenna like: ceiling mount antenna, Wall Mount Antenna, desk antenna, double polar, rubber, bandwide, card mount serial antenna.
We also provide DVB-T/DMB-T/CMMB moving digital TV antenna, low frenquency antenna: 315MHz/433MHz wi-fi digital /wi-fi control /wi-fi wrote water meter /electricity meter antenna, GPS guide antenna, communicate parts, connector and so on. At present, Shenzhen Yetnorson Technology Co.,Lth.has developed more than 100 styles of antenna, with wi-fi internet, wi-fi electronic control, wi-fi end, wi-fi public telephone, wi-fi digital pass, wi-fi Satilla position, wi-fi Radio broadcasting communication field.
