| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | yetnorson |
| Model Number: | ynx-Anti Drone Module |
| Minimum Order Quantity: | 50 pieces |
| Price: | $109.00/pieces 50-99 pieces |
| Packaging Details: | anti drone system fpv 5.8Ghz 20W 43db Counter Signal Jamming RF Uav Anti Drone Module |
| Supply Ability: | 200000 Pair/Pairs per Day we have our own factory |
| Type: | RF Module | Chipset: | All |
|---|---|---|---|
| Supplier Type: | OEM/ODM | Application: | RF Uav Anti Drone Signal Jamming |
| Frequency Range: | 433mhz 0.9G 1.2G 1.5G 2.4G 5.2G 5.8G | Input Power(dBm): | ≤0-20dBm Or Customized |
| Impedance: | 50 Ohm | Working Current: | <10-16A |
| Power: | 5-150W | ALC Range(dB): | ≥5 |
| RF In/Out Connector: | SMA-Female | Working Temperature: | -25~+65 Degree |
| Storage Temperature: | -40 To +85 Degree | Operating Humidity: | 0 To 90%, Relative |
Frequency | 1.2G/1.5G/2.4G/5.8G/900mhz/433mhz/868mhz | MHz |
Work Temperature | —40~80 | ℃ |
Power | 10W~150w | W |
Work Voltage | 24/28/32 | V |
Gain | 45 | dB |
Flatness | ±3 | dB |
Current | 2.9 | A |
Output VSWR | ≤1.5 | |
Output Connector | SMA/F 50Ω | |
Switch Control | high low level current | V |
